optische messverfahren 300

Optical Measuring Methods

GOM TRITOP

Application

  • measuring of 3D component deformations and motions
  • simultaneous analysis of multiple measuring locations at the same time

Technical Data

  • measuring accuracy: 0.2 mm

GOM ATOS

Application

  • digitising of any geometries of body, drivetrain, chassis, electronics and interior components
  • representation of component geometries as STL point clouds
  • polygonised display of component geometry as a basis for CAD and FE modelling
  • quality check (direct comparison of identical component geometries and dimensions for the assessment of deviations)

Technical Data

  • two measuring areas: 500 mm x 400 mm and 1000 mm x 800 mm
  • measuring accuracy: 0.1 mm (according to VDI directive VDI 2634)
